| Quantity: | |
|---|---|
| Bearing No. K CA CC | Boundary dimensions（mm） | Basic load ratings(kN) | Weight | |||
| d | D | B | Cr | Cor | (Kg) | |
 22308 | 40 | 90 | 33 | 121 | 128 | 0.974 |
| 22309 | 45 | 100 | 36 | 148 | 167 | 1.33 |
| 22310 | 50 | 110 | 40 | 186 | 212 | 1.79 |
| 22311 | 55 | 120 | 43 | 204 | 234 | 2.3 |
| 22312 | 60 | 130 | 46 | 238 | 273 | 2.9 |
| 22313 | 65 | 140 | 48 | 265 | 320 | 3.45 |
| 22314 | 70 | 150 | 51 | 325 | 380 | 4.22 |
| 22315 | 75 | 160 | 55 | 330 | 410 | 5.25 |
| 22316 | 80 | 170 | 58 | 385 | 470 | 6.05 |
| 22317 | 85 | 180 | 60 | 415 | 510 | 7.1 |
| 22318 | 90 | 190 | 64 | 480 | 590 | 8.35 |
| 22319 | 95 | 200 | 67 | 500 | 615 | 9.76 |
| 22320 | 100 | 215 | 73 | 605 | 755 | 12.4 |
| 22322 | 110 | 240 | 80 | 745 | 930 | 17.1 |
| 22324 | 120 | 260 | 86 | 880 | 1120 | 21.5 |
| 22326 | 130 | 280 | 93 | 1000 | 1290 | 26.8 |
| 22328 | 140 | 300 | 102 | 1130 | 1460 | 33.8 |
| 22330 | 150 | 320 | 108 | 1270 | 1750 | 42.7 |
| 22332 | 160 | 340 | 114 | 1410 | 1990 | 50.8 |
| 22334 | 170 | 360 | 120 | 1540 | 2180 | 59.8 |
| 22336 | 180 | 380 | 126 | 1740 | 2560 | 70 |
| 22338 | 190 | 400 | 132 | 1870 | 2790 | 81 |
| 22340 | 200 | 420 | 138 | 2040 | 3050 | 93.2 |
