| Quantity: | |
|---|---|
| Bearing No. | Boundary dimensions（mm） | Basic load ratings(kN) | Weight | |||
| d | D | B | Cr | Cor | (Kg) | |
 30203J2 | 17 | 40 | 13,25 | 19 | 18,6 | 0,075 |
| 30204J2/Q | 20 | 47 | 15,25 | 32 | 28 | 0,12 |
| 30205J2/Q | 25 | 52 | 16,25 | 35,5 | 33,5 | 0,15 |
| 302/28J2 | 28 | 58 | 17,25 | 38 | 41,5 | 0,25 |
| 30206J2/Q | 30 | 62 | 17,25 | 46,5 | 44 | 0,23 |
| 30207J2/Q | 35 | 72 | 18,25 | 58,5 | 56 | 0,32 |
| 30208J2/Q | 40 | 80 | 19,75 | 71 | 68 | 0,42 |
| 30209J2/Q | 45 | 85 | 20,75 | 76,5 | 76,5 | 0,48 |
| 30210J2/Q | 50 | 90 | 21,75 | 86,5 | 91,5 | 0,54 |
| 30211J2/Q | 55 | 100 | 22,75 | 104 | 106 | 0,70 |
| 30212J2/Q | 60 | 110 | 23,75 | 112 | 114 | 0,88 |
| 30213J2/Q | 65 | 120 | 24,75 | 132 | 134 | 1,15 |
| 30214J2/Q | 70 | 125 | 26,25 | 125 | 156 | 1,25 |
| 30215J2/Q | 75 | 130 | 27,25 | 140 | 176 | 1,40 |
| 30216J2/Q | 80 | 140 | 28,25 | 151 | 183 | 1,60 |
| 30217J2/Q | 85 | 150 | 30,5 | 176 | 220 | 2,05 |
| 30218J2 | 90 | 160 | 32,5 | 194 | 245 | 2,55 |
| 30219J2 | 95 | 170 | 34,5 | 216 | 275 | 3,00 |
| 33020/Q | 100 | 150 | 39 | 224 | 390 | 2,40 |
| 30220J2 | 100 | 180 | 37 | 246 | 320 | 3,65 |
| 33021/Q | 105 | 160 | 43 | 246 | 430 | 3,05 |
| 30221J2 | 105 | 190 | 39 | 270 | 355 | 4,25 |
| 33022 | 110 | 170 | 47 | 281 | 500 | 3,85 |
| 30222J2 | 110 | 200 | 41 | 308 | 405 | 5,10 |
| 33024 | 120 | 180 | 48 | 292 | 540 | 4,20 |
| 30224J2 | 120 | 215 | 43,5 | 341 | 465 | 6,15 |
| 30226J2 | 130 | 230 | 43,75 | 369 | 490 | 7,60 |
| 30228J2 | 140 | 250 | 45,75 | 418 | 570 | 8,65 |
| 30230 | 150 | 270 | 49 | 429 | 560 | 11,0 |
| 30232J2 | 160 | 290 | 52 | 528 | 735 | 13,0 |
| 30234J2 | 170 | 310 | 57 | 616 | 865 | 19,0 |
| 30236J2 | 180 | 320 | 57 | 583 | 815 | 20,0 |
| 30238J2 | 190 | 340 | 60 | 721 | 1000 | 24,0 |
| 30240J2 | 200 | 360 | 64 | 792 | 1120 | 25,0 |
